DT-DA01 AI Intelligent Tracking Board
Share to:

DT-DA01 AI Intelligent Tracking Board

DT-D01A is a revolutionary AI visual perception and tracking kit designed specifically for time travel aircraft, integrating advanced target tracking algorithms and intelligent flight control algorithms to automatically detect, lock, track, and accurately strike static and dynamic targets. During the flight, AI tracking algorithms evaluate and dynamically adjust the drone's attitude in real-time, effectively addressing the risk of loss of control caused by signal interruption in strong electromagnetic interference environments, significantly improving tracking accuracy and strike success rate.
The introduction of AI guidance technology not only revolutionizes the combat mode of unmanned aerial vehicles, greatly enhancing their autonomous combat capabilities, but also reduces reliance on pilot operation skills, comprehensively improves task execution efficiency, and redefines the practical application value of time traveling aircraft in high interference environments.
Product Details

Product Features

  • By integrating advanced algorithms, high-speed and accurate target recognition and strike capabilities have been achieved, revolutionizing the task execution mode of unmanned aerial vehicles and significantly improving their autonomous approach and continuous tracking capabilities in complex environments, greatly reducing their reliance on pilot operation experience.

  • Based on AI object detection algorithms, it performs excellently in ultra long distance target locking, accurately identifying and locking vehicle targets up to 800 meters away. (Do not specify the YOLO algorithm we use)

  • Equipped with high-performance AI SOC processors and deep learning algorithms, it can extract target information in real-time from video streams, accurately lock static or dynamic targets, and achieve stable, high-precision continuous tracking.

  • After locking onto the target, AI tracking algorithms dynamically adjust tracking strategies based on real-time feedback data, effectively addressing various uncertain factors such as target movement, occlusion, and environmental changes.

  • Having strong anti-interference ability, even in complex environments such as strong electromagnetic interference or temporary signal loss, it can still rely on AI algorithms to achieve continuous tracking and precise approach of targets.

Performance advantage


Technical Specifications


physical parameters

Size

51 × 48 × 25mm (with casing)/

38 × 38 × 17mm (without casing)

weight

65.7g (with casing)/<20g (without casing)

Typical power consumption

6W

Operating Temperature

-40°~+85°

power supply

12V~30V/1A

   Platform parameters

Image input

MIPI (visible light)/UVC (thermal infrared)

image output

CVBS

Input image resolution

1080P/4K (visible light), 384/640 (thermal infrared)

control protocol

CRSF

Support FPV firmware (platform)

BetaFlight/APM/Pix4

Recommended range for lens installation elevation angle

15°~45°

algorithm parameters

focal length

4mm/8mm

object tracking

Automatic recognition/manual specification

Minimum tracking target size

8 × 8 pixels

intelligent tracking

Adaptive tracking/memory tracking

Track target category

People, cars

Tracking frame rate

30fps

Strike distance

800 meters (vehicle)/200 meters (person)
