DT-084C three-axis four light lightweight pan tilt camera
The DT-084C four light pan tilt camera is a lightweight composite sensor drone payload that integrates visible light/infrared/laser ranging. Supports dual channel visible light 4K resolution photography and video recording, equipped with a three-axis stabilizing gimbal, supports stable observation and tracking under high-speed motion, and achieves fast target positioning with 1200 meter laser ranging. Equipped with a 4T computing power AI chip, it can automatically recognize targets such as personnel and vehicles. The total weight of the machine is less than 250g, suitable for scenarios such as power inspection and emergency rescue, achieving a full process closed-loop from wide area reconnaissance to precise positioning. The PTZ camera has been adapted to multiple mainstream flight control platforms in China, enabling seamless integration with flight control systems; And it can be connected to the corresponding display and control software platform to assist customers in quickly comp
Product Details
Product Features
Support dual channel visible light ultra high definition 4K resolution photography and recording;
Infrared supports special functions such as over temperature alarm, point temperature measurement, area temperature measurement, color palette, super-resolution, 16X digital zoom, etc;
Built in 4T computing power, supports visible light and infrared AI target automatic recognition and intelligent tracking:
Support laser ranging and calculate target coordinates by combining drone position and attitude;
The gimbal has the ability to move in three degrees of freedom: azimuth, pitch, and roll;
Support multiple working modes such as heading locking, manual search, following, attitude stabilization, tracking, etc
Capable of locking/unlocking targets, outputting images with tracking frames after locking;
Target tracking has the ability to resist natural interference;
Supporting memory tracking, the target can be captured again in a short period of time after a brief day of loss,
Product Application
Suitable for mobile platforms such as drones, unmanned vehicles, robots, etc., applied in scenarios such as reconnaissance, border patrol, personnel search and rescue, forest fire prevention, etc
infrared thermography
detector type
Uncooled focal plane detector
Working band
8 μm～14 μm
Detector resolution
640×512
sensitivity
NETD≤50mK
Super-resolution
1280 × 1024 (optional)
pixel size
12 μm
focal length
19mm
Field of view angle
22.8 ° × 18.4 ° (±5%）
Measuring range
20 ℃~+150 ℃/± 2 ℃ or ± 2% (high sensitivity)
0 ℃~+500 ℃/± 3 ℃ or ± 3% (low sensitivity)
feature
16X digital zoom, over temperature alarm, point temperature measurement, area temperature measurement, color palette
Visible light camera
sensor
8 MP 1/2.8 "CMOS * 2
focal length
Wide angle: 8mm telephoto: 25mm
aperture
Wide angle: F1.6 telephoto: F3.5
field of view
Wide angle: 48.8 °
Telephoto: 15 °
magnification
zoom 80X
4K 3840*2160，JPG
video
4k 3840*2160 @30fps,MP4
encoding format
H.264/H.265
laser ranging
wavelength
905nm
measuring range
5-1.2km (under visibility conditions of ≥ 5km, for large targets (buildings))
